Product information "Shining3D EinStar Handheld 3D Scanner"

Shining 3D EinStar

EINSTAR is our most affordable 3D scanner ever! You can digitize the world around you like never before!

With EINSTAR, you can capture stable and precise details at high speed and with high data quality. Start 3D scanning with EINSTAR today.

Shining3D EinStar Handheld 3D Scanner Video

Multiple applications

Supports multiple data formats, compatible with 3D printers and 3D design software Design software.

• 3D printing
• Digital Archiving
• Education
• Culture and art
• VR&AR

High data quality

Quickly and easily capture high-density point cloud data with point spacing down to 0.1 mm.

High color fidelity

Benefit from the integrated RGB colour camera.
3D data with authentic colours.

Detail enhancement technology

Built-in detail enhancement technology optimizes the point cloud for complete data capture.

Optimized user experience

Smooth and fast, scan speed up to 14 FPS.

• Intelligent tracking performance
• Automatic alignment
• Intelligent algorithm

Stable outdoor scanning

Equipped with 3 infrared VCSEL projectors, 2 stereo depth cameras and 1 RGB camera, Einstar can capture precise scan data and produce stable results outdoors. Provides flexible working distance for small and large objects.

Extremely easy to operate

• Ergonomic design
• Single USB cable for data transfer and power supply
• Clear and elegant workflow for scanning and post-processing
• Easy setup, plug and play

Comfortable for the eyes, easy to scan hair

• No projector light during scanning.
• Comfortable and safe for the eyes.
• Turn on "hair mode" to get enough hair data for a human scan and improve the data's completeness.

TECHNICAL DATA EINSTAR:

Light source: Infrared VCSEL structured light*
Point spacing: 0.1 mm ~ 3 mm
Effective working distance: 160 mm to 1400 mm
Optimum working distance: 400 mm
FOV (under optimum working distance): 434 mm x 379 mm
Scan rate: Up to 14 fps
Data Alignment Mode: Texture/Feature/Hybrid Alignment/Global Marks*
Full-colour scanning: Yes
Outdoor scanning: Yes
Output formats: OBJ, STL, PLY, ASC, 3MF, P3
Scanner weight: 0.5 kg
Scanner dimensions: 220 mm x 46 mm x 55 mm
Carrying case dimensions: 245 mm x 245 mm x 90 mm
Interface: USB 2.0 or higher
Supported OS: Windows 10/11 64-bit

• Einstar-EN-20220914-V1-2.pdf
